Measurements per EIA standards unless noted above. Specifications subject to change without notice or obligation.
2003.0310NA(U)
B9200319C Printed in Japan
Transmitter Specifications
Measurements made per EIA standard TIA/EIA-603
Power Output 70 W Adjustable to 30 W 50 W Adjustable to 5 W 40 W Adjustable to 5 W
Modulation 16K0F3E 16K0F3E ,11K0F3E
Maximum Deviation 5 kHz 5.0 / 2.5 kHz
Conducted Spurious Emissions
70 dB Below Carrier
Audio Distortion
(
@1 kHz
)
<
3 %
Receiver Specifications
Measurements made per EIA standard TIA/EIA-603
Circuit Type Double-conversion Super-heterodyne
Sensitivity(EIA 12 dB SINAD)
0.25 µV 0.25 µV
Adjacent Channel Selectivity
85 dB
Intermodulation 75 dB 76 dB
Spurious and Image Rejection
85 dB 90 dB
Audio Output 5 W @ 4 Ohms w/ 3 % THD
10 W @ 4 Ohms w/ 3 % THD
(
Optional MLS-100
)
General Specifications
Frequency Range 29.7-37 MHz (A) 134-160 MHz (A) 400-430 MHz (A)
37-50 MHz (B) 148-174 MHz (C) 450-490 MHz (D)
480-512 MHz (F)
Number of Channels 250 Channels
Channel Spacing 20 kHz 12.5/25/30 kHz
PLL Steps 5/6.25 kHz 2.5/5/6.25 kHz 2.5/5/6.25 kHz
Power Supply Voltage 13.8 VDC ±
20 %
Current Consumption
STBY 400 mA
RX 2.1 A
TX 12 A
Operating Temperature Range
–22° F to
+
140° F (–30° C to
+
60° C)
Frequency Stability Better than ±5 ppm Better than ±2.5 ppm
RF Input-Output Impedance 50 Ohms
Audio Output Impedance 4 Ohms
Dimensions 7"(W) X 2.4"(H) X 7.7"(D) (178 X 60 X 195 mm)
Weight 4.9 lb. (2.2 kg)
VX-4000L VX-4000V VX-4000U
Specifications
Standard
MIL 810C Methods/Procedures
MIL 810D Methods/Procedures
MIL 810E Methods/Procedures
Low Pressure
High Temperature 501.1/Procedure 1, 2
Low Temperature 502.1/Procedure 1
Temperature Shock 503.1/Procedure 1
Solar Radiation 505.1/Procedure 1
Rain*
Humidity 507.1/Procedure 2
Salt Fog
Dust
Vibration 514.2/Procedure 8, 10
Shock 516.2/Procedure 1, 5
500.2/Procedure 2
501.2/Procedure 1, 2
502.2/Procedure 1, 2
503.2/Procedure 1
505.2/Procedure 1
506.2/Procedure 1, 2
507.2/Procedure 2
509.2/Procedure 1
510.2/Procedure 1
514.3/Procedure 1 Cat. 10
516.3/Procedure 1, 4
500.3/Procedure 2
501.3/Procedure 1, 2
502.3/Procedure 1, 2
503.3/Procedure 1
505.3/Procedure 1
506.3/Procedure 1, 2
507.3/Procedure 2
509.3/Procedure 1
510.3/Procedure 1
514.4/Procedure 1 Cat. 10
516.4/Procedure 1, 4
Applicable MIL-STD
*Control Head Only
85 dB/ 75 dB
(25 kHz/12.5 kHz)
80 dB/ 70 dB
(25 kHz/12.5 kHz)
Sukagawa Division
Trondule Co., Ltd.
ISO9001 certification
Sukagawa Division
Trondule Co., Ltd.
ISO14001 certification
Vertex Standard
US Headquarters
10900 Walker Street, Cypress, CA 90630, U.S.A.
Phone 714/827-7600; Fax 714/827-8100
http://www.vxstdusa.com
