PWC-1500 Parts List
Item No. Description Part Number Item No. Description Part Number
P1 Main Tank Cover, round cl1 9210 M1 Upper Plate cl5 9609
P2 Top Cover, square cl5 9600 M2 Mounting Plate cl1 9217
P3 Upper Front Panel cl5 9601 M3 Left Side Panel cl5 9610
P4 Lower Front Panel cl5 9602 M4 Right Side Panel cl5 9611
P5 Faucet Cover cl5 9603 M5 Rear cover cl1 9236
P6 Base cl5 9604 M6
P7 Drip Tray Set cl5 9605 M7 Screw
P8 Handle cl1 9235 M8 Screw
P9 Faucet, Cold Water cl5 9606 M9 Condensor cl5 9612
P10 Faucet, Hot Water cl5 9607 M10 Dryer cl1 9241
P11 Strain Relief M11 Capillary Tube
P12 M12
P13 Nut, Faucet cl5 9607 M13 Spring Clip cl1 9215
P14 Rubber Pad cl1 9249 M14
P15 1/4" tubing M15 Screw, 5 x 22 cl1 9257
P16 M16 Screw, 4 x 25 cl1 9255
P17 Dust Cover cl1 9201 M17 Screw cl5 9613
P18 Fitting, elbow, 1/4 x 1/4 cl5 9608 M18 Screw, 3 x 8 cl5 9614
M19 Screw, 4 x 12 cl5 9615
E1 PC Board cl1 9253 M20 Pivot Pin cl5 9616
E2 Cold Temperature Switch cl1 9237
E3 Power Switch cl1 9238 O1 Indicating Panel, (sticker) cl5 9622
E4 Fuse Housing cl1 9252 O2
E5 Fuse O3 Mechanical Float Valve cl1 9233
E6 Screw, 4 x 6 cl1 9256
E7 Compressor cl1 9218 Hotlock Safety tab cl5 9623
E8 Power Cord
Vertex Water Products 2006
