PWC-1500 Parts List
Item No. Description Part Number Item No. Description Part Number
H1 Hot Tank cl5 9617 C1 Cold Water Tank cl1 9223
H2 96ºC Temperature Sensor cl1 9250 C2
H3 82ºC Temperature Sensor cl1 9251 C3 Silicon Gasket cl1 9224
H4 Screw 5 x 22 cl1 9257 C4 Cold Tank Outlet Connector cl1 9242
H5 C5
H6 C6 Nut, Faucet cl5 9620
H7 Screw, Hot Tank cl1 9245 C7 Insulating Foam, Cold Tank cl1 9222
H8 Silicon Tube Elbow, 175 x 4 cl1 9230 C8 Bottom Insulating Foam cl5 9621
H9 Silicon Tube Elbow, 160 x 4 cl1 9227 C9
H10 Silicon Tube St, 5 x 250 cl5 9618 C10 Silicon Tube Elbow, 75 x 4 cl1 9244
H11 Silcon Vent "T" Tube cl1 9225 C11 Insulating Sleeve cl1 9214
H12
H13
H14 Silicon Tube Elbow 50x60x4 cl1 9028
H15 Drain Fitting Nut cl1 9240
H16 Tank Drain Connector cl1 9246
H17 Drain Plug cl1 9248
H18 Sillicon Plug cl5 9619
Vertex Water Products 2006
2
