PWC – 450
PureWaterCooler
Copyright 2011 Vertex Water Products
5.1 Drain water from hot tank by removing bottom
drain cap.
5.2 Remove top cover and left side cover (sec. 3)
5.3 Remove (4) electrical connectors from hot tank
temperature sensors.
5.4 Remove (2) electrical connectors from hot tank
heater coil leads.
5. Removing/Replacing Hot Tank.
