Vertex PWC-500 - Internal Component Disconnections

PWC – 500/1000/1010/1500
PureWaterCooler
Copyright 2006 Vertex Water Products
5.7 Disconnect electrical connector at circuit board.
5.8 Hot tank is now accessible
5.9 Remove silicon tubing – 4 places
5.10 Disconnect 2 electrical connectors at bottom
of tank
5.11 Remove (1) hot tank screw from below
• Removing/Replacing Hot Tank
Cont.
