Vertex PWC-500 - Lever Assembly Installation and Testing

PWC – 500/1000/1010/1500
PureWaterCooler
Copyright 2006 Vertex Water Products
• Faucet Repair
Cont.
6.4 Lift out the lever assembly. Obtain a new
lever assembly and install in the faucet
base. Hand tighten the lever assembly
securely.
6.5 Fill the cooler with water and check for leaks
Note:
When removing and replacing the lever assembly,
make sure the rubber seal and the lever are
connected together. To connect the seal to the lever
assembly, firmly push the seal on to the
button on the lever assembly.
6.6 Reinstall the top panel.
Button Seal
Correctly connected seal/lever assembly
(shown with front panel removed)
