Figure 2.2 Vertiv™ Liebert® APM2 Lithium Battery Modules
Item Description Item Description
1 Handle 7 Front Panel of Liebert® APM2 lithium battery module
2 12 V external input interface 8 Retaining pin
3 MCB low voltage control switch 9 Communication cable wiring ports
4 RS-485 communication interface 10 Power cable wiring port
5 Lock switch 11 Rear Panel of Liebert® APM2 lithium battery module
6 Status indicator 12 Heat sink
Figure 2.3 Lock Switch
