Vertiv Liebert CR025 User Manual

126 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Liebert® CRV4 Series

User Manual

Precision Air Conditioning

Table of Contents

Questions and Answers:

D
Dr. Patricia JoyceAug 17, 2025
What to do if my Vertiv Air Conditioner compressor cannot be started?
- D
  Daniel BrownAug 17, 2025
  If the compressor of your Vertiv Air Conditioner fails to start, begin by checking the main power supply for under-voltage, over-voltage, and phase loss. Then, inspect the compressor MCB, contactor, and connecting cables. Review the unit's alarm records, replace any damaged components, and power it on again. If the compressor coils are shorted or burnt, check the motor and replace it if necessary.
J
john86Aug 20, 2025
What to do if my Vertiv Liebert CR025 Air Conditioner compressor is too noisy?
- B
  Brian Lowery MDAug 20, 2025
  If the compressor of your Vertiv Air Conditioner is excessively noisy, it may be due to liquid return or worn-out bearings. Address liquid return by referring to the troubleshooting steps for 'Low suction pressure' or 'liquid returned'. If the bearings are worn due to lubricant loss, add lubricant.
S
Stacy GriffinAug 22, 2025
What to do if my Vertiv Liebert CR025 Air Conditioner's compressor stops after running for 3 minutes?
- D
  dale65Aug 22, 2025
  If the compressor of your Vertiv Air Conditioner stops after running for 3 minutes, and the contactor opens, the issue might be related to refrigerant leakage causing low pressure. Check the suction pressure. Also, inspect the circuit and calibrate the low-pressure sensor to ensure its reading is within ±0.3 bar of the actual pressure.
D
Dr. Nancy WalkerAug 25, 2025
What to do if my Vertiv Liebert CR025's contactor does not get closed, and the compressor does not start?
- D
  David Charles PhDAug 26, 2025
  If the contactor of your Vertiv Air Conditioner doesn't close and the compressor doesn't start, check the micro-processing controller. Also, check for a high-pressure alarm, a discharging temperature alarm, or a low-pressure alarm in the history. Verify that the contactor can energize and inspect the compressor driver. If the compressor's internal protector is open, check if the compressor coil is an open circuit and allow it to cool for automatic restoration.
A
Anna ThomasAug 27, 2025
Why is my Vertiv Air Conditioner's compressor over temperature?
- L
  Leslie WallaceAug 28, 2025
  If your Vertiv Air Conditioner's compressor is overheating, it could be due to a high compression ratio. Check the settings of the HP and LP switches, and inspect the condenser for clogs. Also, make sure that the fans of both the evaporator and condenser are functioning normally. If the suction overheat temperature is too high, regulate the EEV or add the correct amount of refrigerant.
J
jacksonkimberlyAug 30, 2025
How to fix high pressure protection in Vertiv Liebert CR025?
- L
  Lindsay LeachAug 30, 2025
  To resolve high pressure protection issues in your Vertiv Air Conditioner, start by cleaning the condenser. If you have an air-cooled system, check the condenser fan. Also, verify that the system has not been overcharged with refrigerant by checking the sub-cooling degree.
F
fitzpatricksusanSep 1, 2025
Why is my Vertiv Air Conditioner showing low suction pressure or liquid returned?
- R
  Robert SuttonSep 1, 2025
  If your Vertiv Air Conditioner shows low suction pressure or liquid return, it may be due to several reasons. First, check for refrigerant leaks, seal any leaks found, and add refrigerant. Next, replace the air filter if it's dirty and replace the filter dryer if it is clogged. Also, check the control board of the Electronic Expansion Valve (EEV), replace the sensing element if it is faulty, check the air supply and return systems for improper airflow distribution and check whether the condenser is faulty due to low condensing pressure.
C
clinedavidSep 4, 2025
How to resolve ineffective heating in Vertiv Liebert CR025 after contactor closes?
- B
  Benjamin MurphySep 4, 2025
  If the contactor in your Vertiv Air Conditioner closes but heating remains ineffective, first check if the heater’s MCB is turned ON. Then, check whether the L1, L2, and L3 voltages are normal when the contactor is energized. Also, turn off the power supply and physically inspect the heater for signs of being burned out.
H
heathrachelSep 6, 2025
How to troubleshoot Vertiv Liebert CR025 Air Conditioner EC fan that won't start?
- R
  Robert MorganSep 6, 2025
  If the EC fan of your Vertiv Air Conditioner fails to start, check whether the fan MCB is closed and if the power voltage of each phase is normal. Check J15 on the micro-processing control board to see if the control board is faulty. Check the alarm lamp on the fan power module to determine if it is working correctly. Check L1, L2, and L3 of the fan for power failure, phase loss, and low voltage. Check whether the analog output is within the specific range of 0 Vdc to 10 Vdc, whether the motor is clogged, too hot, or if there is a Hall failure.
L
Logan HarrisSep 9, 2025
Why Vertiv Liebert CR025 heating system does not start, the contactor does not close?
- Z
  Zachary RamirezSep 9, 2025
  If the heating system of your Vertiv Air Conditioner does not start and the contactor doesn't close, check the state of the micro-processing controller to confirm if there is a heating command. Also, check the safety device of the heating system. Use a multi-meter to measure the resistance on both ends of the temperature controller; if the resistance is very large, it indicates that the safety device may be open. Next, check whether the fuse is open and the temperature controller is damaged. Measure the resistance of the heater with an ohmmeter to determine if the heater is damaged.

Vertiv Liebert CR025 Specifications

General

Brand	Vertiv
Model	Liebert CR025
Category	Air Conditioner
Language	English

Summary

Safety Precautions and Measures

Chapter 1: Introduction

1.4. Main Components

Details the key components of the Liebert CRV4 indoor unit.

1.4.1. EC Compressor

Details the EC compressor features: low noise, vibration, high reliability.

1.4.2. Evaporator

1.4.3. Electronic Expansion Valve (EEV)

Chapter 2: Installation

2.1. Equipment Room Consideration

2.2. Installation Space Requirements

2.2.1. Maintenance Space Requirements for Liebert CRV4

2.3. Environmental Requirements

2.3.1. Operating Environment

2.4. Refrigerant Charging Requirement

Explains the need for per-specified quality refrigerant (R410A) for optimal efficiency.

2.5. Transportation, Unpacking and Inspection

Procedures for safely transporting, unpacking, and inspecting the unit.

Chapter 3: Mechanical Installation

3.1. System Arrangement during Installation

Details system arrangement and layout considerations for installation.

3.1.3. Mechanical Parameters

Displays mechanical parameters of the indoor unit including dimensions and weight.

3.2. Installation of the Indoor Unit

Step-by-step guide for installing the indoor unit, including leveling.

3.2.1. Leveling the Cabinet

Step-by-step illustration for leveling the cabinet using leveling feet.

3.2.2. Removing the Leveling Feet and Fastening

Instructions for removing leveling feet and fixing the cabinet.

3.3. Unit Piping Installation

Outlines the four types of piping to be joined and general piping considerations.

3.3.4. Connection of the Copper Piping between the Indoor and Outdoor Units

Guides connecting indoor and outdoor units via brazed copper piping, mentioning dimensions.

3.4. Charging Refrigerant and Adding Lubricant Oil

Details procedures for charging refrigerant and adding lubricant oil.

3.4.1. Charging Refrigerant

Details standard refrigerant charge amounts for outdoor and indoor units.

3.4.2. Adding Lubricant Oil

Provides guidance on adding lubricant oil, types, and amounts based on pipe OD.

Chapter 4: Electrical Installation

4.1.2. Installation Notes

4.2. Liebert CRV4 Cable Connection of Indoor Unit

Guides on connecting cables for the Liebert CRV4 indoor unit.

4.2.2. Connecting the Power Cable of the Indoor unit

Details connecting supply terminals L1-L3, N, PE to their counterparts.

4.2.3. Connecting the Control Cables

Chapter 5: Start-up Commissioning

5.2. Power-On Commissioning

Procedures for powering on and commissioning the system.

5.2.1. Preparation Before Commissioning

Mechanical and electrical preparation steps before powering on the unit.

5.2.2. Commissioning Procedures

Step-by-step procedures for vacuuming, charging refrigerant, and dynamic charging.

Chapter 6: Micro-Controller (Color Screen)

6.3. Control Screen

Details the interface screens for controlling the unit.

6.3.1. Main Screen

6.3.2. Main Interface Control Mode

6.5. Alarm Information

How to access Alarm Information, including alarm status and history.

6.5.1. Temperature and Humidity

6.5.2. Parameter Setting

Chapter 7: Micro-Controller (Text-screen)

7.4. Control Buttons

7.4.1. Function Description

7.5. Control Screen

Describes the control screen interface and its displays.

7.5.2. Main Screen

7.6.3. Alarm Information

Accessing Alarm Info to view active and history alarm information.

7.6.4. Temperature & Humidity Settings

7.6.5. Parameter Settings

Chapter 8: System Operation and Maintenance

8.1. Routine Maintenance & Inspection Items (Monthly)

8.2. Routine Maintenance and Inspection (Semi-annually)

8.4. Maintenance of Electrical Control Utilities

8.4.1. Maintenance of Electrical Parts

8.4.2. Maintenance of Control System

8.9. Refrigerating System Maintenance

Maintenance instructions for the refrigerating system components.

8.9.5. Compressor

Chapter 9: Troubleshooting

9.1. Troubleshooting of the Fan

9.2. Troubleshooting of the Heating System

9.3. Troubleshooting of Compressor and Cooling System

Troubleshooting steps for compressor not starting or stopping, and other cooling system issues.
