Liebert® CRV4 Series
User Manual
Precision Air Conditioning

Table of Contents

Questions and Answers

  • L
    Lisa OrtegaAug 18, 2025
    What to do if my Vertiv Liebert CR045 Air Conditioner compressor cannot be started?
    • K
      Kathleen NortonAug 18, 2025
      If the compressor of your Vertiv Air Conditioner fails to start, begin by checking the main power supply for under-voltage, over-voltage, and phase loss. Then, inspect the compressor MCB, contactor, and connecting cables. Review the unit's alarm records, replace any damaged components, and power it on again. If the compressor coils are shorted or burnt, check the motor and replace it if necessary.
  • E
    eparkerAug 20, 2025
    What to do if my Vertiv Air Conditioner compressor is too noisy?
    • D
      David FordAug 20, 2025
      If the compressor of your Vertiv Air Conditioner is excessively noisy, it may be due to liquid return or worn-out bearings. Address liquid return by referring to the troubleshooting steps for 'Low suction pressure' or 'liquid returned'. If the bearings are worn due to lubricant loss, add lubricant.
  • D
    Danielle ZavalaAug 23, 2025
    What to do if my Vertiv Liebert CR045's compressor stops after running for 3 minutes?
    • K
      Kathy RodriguezAug 23, 2025
      If the compressor of your Vertiv Air Conditioner stops after running for 3 minutes, and the contactor opens, the issue might be related to refrigerant leakage causing low pressure. Check the suction pressure. Also, inspect the circuit and calibrate the low-pressure sensor to ensure its reading is within ±0.3 bar of the actual pressure.
  • C
    Caleb DyerAug 26, 2025
    What to do if my Vertiv Liebert CR045's contactor does not get closed, and the compressor does not start?
    • S
      Stephanie RodriguezAug 26, 2025
      If the contactor of your Vertiv Air Conditioner doesn't close and the compressor doesn't start, check the micro-processing controller. Also, check for a high-pressure alarm, a discharging temperature alarm, or a low-pressure alarm in the history. Verify that the contactor can energize and inspect the compressor driver. If the compressor's internal protector is open, check if the compressor coil is an open circuit and allow it to cool for automatic restoration.
  • J
    Jerry MartinAug 27, 2025
    Why is my Vertiv Air Conditioner's compressor over temperature?
    • A
      aaronmoyerAug 27, 2025
      If your Vertiv Air Conditioner's compressor is overheating, it could be due to a high compression ratio. Check the settings of the HP and LP switches, and inspect the condenser for clogs. Also, make sure that the fans of both the evaporator and condenser are functioning normally. If the suction overheat temperature is too high, regulate the EEV or add the correct amount of refrigerant.
  • C
    Cheryl JohnsonAug 30, 2025
    How to fix high pressure protection in Vertiv Air Conditioner?
    • B
      bcobbAug 30, 2025
      To resolve high pressure protection issues in your Vertiv Air Conditioner, start by cleaning the condenser. If you have an air-cooled system, check the condenser fan. Also, verify that the system has not been overcharged with refrigerant by checking the sub-cooling degree.
  • S
    Sarah CarterSep 1, 2025
    Why is my Vertiv Liebert CR045 showing low suction pressure or liquid returned?
    • S
      Sheila SmithSep 2, 2025
      If your Vertiv Air Conditioner shows low suction pressure or liquid return, it may be due to several reasons. First, check for refrigerant leaks, seal any leaks found, and add refrigerant. Next, replace the air filter if it's dirty and replace the filter dryer if it is clogged. Also, check the control board of the Electronic Expansion Valve (EEV), replace the sensing element if it is faulty, check the air supply and return systems for improper airflow distribution and check whether the condenser is faulty due to low condensing pressure.
  • L
    Laura McmahonSep 4, 2025
    How to resolve ineffective heating in Vertiv Air Conditioner after contactor closes?
    • K
      Kimberly ReynoldsSep 4, 2025
      If the contactor in your Vertiv Air Conditioner closes but heating remains ineffective, first check if the heater’s MCB is turned ON. Then, check whether the L1, L2, and L3 voltages are normal when the contactor is energized. Also, turn off the power supply and physically inspect the heater for signs of being burned out.
  • C
    Caleb JohnsonSep 6, 2025
    How to troubleshoot Vertiv Air Conditioner EC fan that won't start?
    • J
      Joshua KimSep 7, 2025
      If the EC fan of your Vertiv Air Conditioner fails to start, check whether the fan MCB is closed and if the power voltage of each phase is normal. Check J15 on the micro-processing control board to see if the control board is faulty. Check the alarm lamp on the fan power module to determine if it is working correctly. Check L1, L2, and L3 of the fan for power failure, phase loss, and low voltage. Check whether the analog output is within the specific range of 0 Vdc to 10 Vdc, whether the motor is clogged, too hot, or if there is a Hall failure.
  • M
    Michelle HarrisSep 9, 2025
    Why Vertiv Liebert CR045 Air Conditioner heating system does not start, the contactor does not close?
    • S
      Shannon Jenkins IVSep 9, 2025
      If the heating system of your Vertiv Air Conditioner does not start and the contactor doesn't close, check the state of the micro-processing controller to confirm if there is a heating command. Also, check the safety device of the heating system. Use a multi-meter to measure the resistance on both ends of the temperature controller; if the resistance is very large, it indicates that the safety device may be open. Next, check whether the fuse is open and the temperature controller is damaged. Measure the resistance of the heater with an ohmmeter to determine if the heater is damaged.

Summary

Safety Precautions and Measures

Chapter 2: Installation

Chapter 3: Mechanical Installation

3.2. Installation of the Indoor Unit

Step-by-step process for leveling and installing the indoor unit.

3.4. Charging Refrigerant and Adding Lubricant Oil

Procedures for charging refrigerant and adding lubricant oil to the system.

Chapter 4: Electrical Installation

4.2. Liebert CRV4 Cable Connection of Indoor Unit

Details cable connection for the indoor unit, including port locations and terminal connections.

Chapter 5: Start-up Commissioning

5.2. Power-On Commissioning

Chapter 6: Micro-Controller (Color Screen)

6.3. Control Screen

Chapter 7: Micro-Controller (Text-screen)

Chapter 8: System Operation and Maintenance

8.1. Routine Maintenance & Inspection Items (Monthly)

8.9. Refrigerating System Maintenance

Chapter 9: Troubleshooting

9.3. Troubleshooting of Compressor and Cooling System
