Vertiv | Liebert® CRV4 | User Manual 11
Installation
• Removing the pallet
The unit is xed onto the pallet with M8×20 and M8x80 screws, as shown in Figure 2-5. Use a 17 mm open-end
spanner, ratchet spanner or sleeve can be used to remove the screws.
No. Description No. Description
1 Screw M8x20 2 Hexagon head bolt M8x80
Figure 2-5 Screws on the Pallet
2.5.3. Inspection
• Check that the ttings are complete and the components are intact against the packing list. Ensure that
everything is in its designated position.
• If any parts or components are missing or damaged, immediately report to the local oices of the carrier and
Vertiv representative at the earliest.
