Vertiv | Liebert® CRV4 | User Manual 19
Mechanical Installation
3.1.6. Location of Front Air Outlets
The locations of the air outlets at the front are shown in Figure 3-7.
Figure 3-7 Locations of Front Air Outlets (unit: mm)
To prevent damage of the power cables due to wear and tear, the cable entry holes are tted with bushes for
smoother routing of the cabling.
