Vertiv | Liebert® CRV4 | User Manual 16
Mechanical Installation
3.1.3. Mechanical Parameters
The mechanical parameters of the indoor unit are displayed in Figure 3-4 and Table 3-1.
Figure 3-4 Dimensions of Indoor Unit
Table 3-1 Mechanical Parameters of Indoor Unit
Model
Dimensions (W × D × H)
Net Weight (kg)
mm inch
CR025RA1N8S712E30000PV040
(Including anchor bolts)
300×1100×2000 11.8"x43.3"x78.7" 235
CR025HA1N80S02E30000PV041
(Excluding anchor bolts)
300×1200×2200 11.8"x47.2"x86.6" 255
CR035RA1N8S712E30000PV040
(Including anchor bolts)
600×1100×2000 23.6"x43.3"x78.7" 320
CR035HA1N80S02E30000PV041
(Excluding anchor bolts)
600×1200×2200 23.6"x47.2"x86.6" 350
CR045RA1N8S712E30000PV040
(Including anchor bolts)
600×1100×2000 23.6"x43.3"x78.7" 335
CR045HA1N80S02E30000PV041
(Excluding anchor bolts)
600×1200×2200 23.6"x47.2"x86.6" 365
