UNIT TO UNIT NETWORK CONNECTIONS
LIEBERT
®
iCOM™
LIEBERT® CW, LIEBERT® CWA, LIEBERT® DS, LIEBERT® DSE,
LIEBERT® PDX, LIEBERT® PCW
TO / FROM OTHER
NETWORKED UNITS
TB3
P71 P72
P74 P64
E5
P
6
7
P
6
6
P
1
1
P
1
2
P
2
1
P
2
0
P
1
3
P
7
P76
P95
P100
P75
2
RS485
ETHERNET
SITE AND BMS
COMMUNICATION
CONNECTIONS
iCOM™
MICROPROCESSOR
AND I/O BOARD
ETHERNET CABLE
(FIELD SUPPLIED)
TB3
P
2
DETAIL A
-
1 2
A
UNIT-TO-UNIT NETWORKING SWITCH
(FIELD SUPPLIED)
+
P95 DVI-D CABLE CONNECTION
TO 7-INCH ICOM DISPLAY
P100 POWER SUPPLY TO
7-INCH ICOM DISPLAY
