Vertiv™ NetSure™ 5100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
45
Figure 5.4 GMT Distribution Fuse Replacement (List KG)
5.6.4 Circuit Card Replacement Procedures
DANGER! Adhere to the “Important Safety Instructions” presented at the front of this document.
WARNING! Circuit cards used in this power system contain static-sensitive devices. Read the Static Warning at the front of
this document before performing any of the following procedures.
General
The following circuit card replacement procedures can be performed with the system operating.
Circuit Card Locations
Refer to Figure 5.5, Figure 5.6, or Figure 5.7.
GMT Fuse
Safety Cover
