PlaceAnti-Corrosion Barrier Pad Over

Pad Template Before Attaching

Battery Base

components removed in

illustration for clarity

Install Hardware

as Shown (6 Plcs)

(1/2-13)

Guide pins

for lowering cabinet onto

exact location for mounting

(2 plcs)

Guide pins

for lowering cabinet onto

exact location for mounting

(2 plcs)
