Vertiv NetXtend Flex 20

To Next Page

To Previous Page

Place

block in

plastic

caps

Place

block in

plastic

caps

Step 1: Arrange the cables of the block over the stand-off

grooming and place the M307 block on the plastic

cap.

Step 2: Rotate the M307 block towards the snap

hook at the top.

Plastic Clip

Snap Hook

M307 Protection

Block

Stand-off

Grooming
