Vespa GT 125 User Manual

Removing the hub bearings
- Check the state of the bearings being examined
(wear, clearance and noisiness). If faults are de-
tected, do the following.
- Use the specific bearing extractor to remove the
three 15 mm bearings (2 in the crankcase and 1 in
the hub cover).
Specific tooling
001467Y013 Pliers to extract ø 15-mm bearings
Removing the wheel axle bearings
Hold up the hub cover and take out the bearing.
Specific tooling
020376Y Adaptor handle
020477Y Adaptor 37 mm
020483Y 30 mm guide
Engine Vespa GT 125-200
ENG - 118

Vespa GT 125 Specifications

General

Displacement	124 cc
Transmission	Automatic CVT
Rear Brake	140 mm drum
Seat Height	790 mm
Engine Type	Single cylinder, 4-stroke
Cooling System	Air-cooled
Fuel System	Electronic injection
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Rear Suspension	hydraulic shock absorber
