Vespa S 2012 - Air Filter

- Prepare an adequately sized container.
- Unscrew the oil drainage plug and drain out all
the oil.
- Screw in the drainage cap again and fill the hub with the prescribed oil.
Recommended products
AGIP GEAR SAE 80W-90 Lubricant for gearboxes and transmissions.
API GL-4
Characteristic
Rear hub oil
~ 200 cm³
Locking torques (N*m)
Hub oil drainage screw 15 to 17
Air filter
- Remove the helmet compartment.
- Disconnect the air intake pipe from the filter box.
- Undo the indicated fixing screws.
- Remove the left side fairing.
Vespa LX - S 125 3V ie 150 3V ie (2012) Maintenance
MAIN - 41
