SPECIFICATION
Ambient temperature
0~40
Ambient Humidity
30~80%
Hopper capacity
Max.1500units
Each coins drawer
50~300units
Batch preset number display
3 Digits LED
Counting number display
4 Digits LED
Power source
AC110V/60HZ
Power consumption
15W
Dimensions
430*395*330mm
Gross weight
5.33kg
Counting speed
Max. 300 units/min
OPERATION
1.Make sure that the machine is put on level and then turn on the machine.
2.Set an expected batch.
Each channel can be set an expected batch (from 0 to 999). Press the “SET” key
to select the channel, and the “BAT” key, “+ key and “-” key to set the expected
batch number.
Note 1: If some channels set the batch to 0, the machine will not stop this channel
even the drawer is full, unless the “START/STOP” key is pressed or no coin drop
though the channel within 20 seconds.
Note 2: Keep “-” key pressed in 7 seconds can set all the channels to batch 0.
Note 3:The batch setting can be automatically memorized.
