Product voltage :220V Rated power:1800 watts and 1200watts
1.Power on: open the power supply knife of the machine cable. After power
on, all display units will light up once and the buzzer will drop once.
2. Power button: each furnace area has an independent power button.
When you want to start one of the burners, press the power button to turn
on the power and enter the standby state.
3. Standby state: Press the power button as described in the second
operation and enter the standby mode, which displays 0 (0 is not heated).
The standby mode automatically exits and returns to the shutdown state
without any operation for a long time.
The standby state is shown as follows: 0 is the standby state in both furnace areas
4. Heating: for example, if you want to use the furnace area for heating, push the
regulator in the standby state. When the digital display 0 turns into a number, the
furnace area enters the heating mode. As shown in figure 9:
4.1 Power distribution: upper left 220V/1800W
lower left 220V/1200W. (+ / - 10%)
Glass plate
control panel
The above is only the schematic diagram of the structure,
please refer to the actual object.
TIMER lOCK
DOWN
UP
ON/OFF
