VEVOR DT2W - Trouble Codes and Troubleshooting; Product Dimensions and Precautions

E1------- The sensor on the control board is faulty
E2------- Short circuit in thermistor of touch pad
Voltage range: 90V-270V
11. Product dimensions and precautions:
11.1. Product size 288*510*82 (11.3*20.0*3.22 inches) If not including the
foot of the fuselage thickness is 65MM/2.55 inches.
11.2. Roar size 275*495*150mm (10.8*19.48*5.9 inches)
When the machine is embedded, to ensure the normal use of the machine and
better heat dissipation.
Requirements:
1. 30-50mm heat dissipation should be left on the left and right sides and behind.
2. The counter interior should be as large as possible to ensure that enough cold
air is sucked into the machine.
3. Inlet air (cold air) must be separated from outlet air (hot air) space.
4. The air inlet and outlet space of the counter leave air roar.
HEAT DISSIPATION STRUCTURE INSTALLATION DRAWING
Front view
30.00 mm
30.00 mm
left
right
Induction cooker
Counter space
Heat flow
The cold air
Exhaust roar
Heat flow
Exhaust roar
30.00 mm
after
Air inlet
Cupboard door
Induction cooker
Heat flow
Exhaust roar
The cold air
Counter space
Side view
Note: if the product is used on the table, because the bottom will produce
temperature during the use process, please use high temperature resistant
flame retardant material for the table such as marble....... And so on.
TROUBLE CODE AND TROUBLESHOOTING
5
