VEVOR JN08 - Recommended Accessories; Technical Data and Product Structure

- 7 -
Technical Data
Model
JN08
JN13
Phase
1
1
Voltage
AC 240V
AC 240V
Wattage
8kW
13.8kW
Max. Amp. Load
33A
58A
Min. Required Circuit Breaker
40A
70A
Min. Wire Size AWG Copper
10#
6#
Min. Water Flow to Activate
0.4GPM
0.53GPM
Product Dimension
358x246x85MM
Water Connections NPT
1/2”
Note: *Suitable recognized strain relief means shall be provided when
the product is installed.
Recommended Accessories
Subject
JN08
JN13
Water inlet pipe
1pc (NPT1/2” connector)
1pc (NPT1/2” connector)
Water outlet pipe
1pc (NPT1/2” connector)
1pc (NPT1/2” connector)
Circuit breaker
40A
70A
Power cable
10AWG
6AWG
 Length of power cable need to calculated according to distance between
heater and circuit breaker.
 Above mentioned accessories are excluded.
