VEVOR LP18A - Tank Cover; Tank; Dispensing Valve; Supporting Block

- 6 -
Diagram for reference only, please in kind prevail!
No.
Part name
No.
Part name
No.
Part name
1
Tank cover
9
Evaporator
17
Compressor
2
Pump tube
10
Supporting block
18
Fan motor
3
Tank
11
Pump motor
19
Condenser
4
Gasket of tank
12
Side panel(right)
20
Side panel(left)
5
Pump cover
13
Switch
21
Back panel
6
Dispensing valve
14
Front panel
22
Bearing sleeve
7
O-ring
15
Cover for drip tray
23
Impeller
8
Handle
16
Drip tray
24
Fastener
