CLAWBOT BUILDING INSTRUCTIONS
4
Attaching the Potentiometer (continued)
Slide the structure back in place. Both C-Channels should now open to the right.
Building Tip - Potentiometer Range of Motion
At this step, make sure the arm rotates within the potentiometer’s range
of motion.
Forcing the potentiometer beyond its mechanical stops will damage the
sensor.
