5
Jumpers
Jumper Name Description Page
JBAT
CMOS RAM Clear
3-pin Block P.6
JP2
USB Power On Enable/Disabled
3-pin Block P.7
JP3
USB Power On Enable/Disabled
3-pin Block P.7
Connectors
Connector Name Description Page
ATXPWR Power Connector 24-pin Block P.21
ATX12V ATX 12V Power Connector 8-pin Block P.22
PS2KBMS PS/2 Mouse & PS/2 Keyboard Conn. 6-pin Female P.22
UL2 USB2.0 Port Connector 4-pin Connector P.22
UL1 RJ45 LAN Port Over USB Connector RJ-45 Connector P.22
CN3 Audio Connector 3 phone jack Connector P.22
FDD Floppy Driver Connector 34-pin Block P.23
SATA1/2 Serial ATA IDE Connector 7-pin Connector P.24
IDE1/IDE2 Primary/Secondary IDE Connector 40-pin Block P.23
Headers
Header Name Description Page
JAUDIO MIC header for front Panel 9-pin Block P.25
USB2, USB3 USB Port Headers 9-pin Block P.25
HD LED IDE activity LED 2-pin Block P.25
RESET Reset switch lead 2-pin Block P.25
SPEAK PC Speaker connector 4-pin Block P.25
PWR LED Power LED 2-pin Block P.25
PWR BTN Power switch 2-pin Block P.26
SFAN1, SFAN2 ,CPUFAN FAN Headers 3-pin / 4-pin Block P.26
VGA VGA Conn.
15-pin Block
P.24
PARALLEL Parallel Port Connector 26-pin Block e P.26
COM1 Serial Port COM1 Connector 9-pin Block P.26
IR IR infrared module Headers 5-pin Block P.26
CD
_
IN CD Audio-In Headers 4-pin Block P.26
Expansion Sockets
Socket/Slot Name Description Page
LGA 775 Socket CPU Socket LGA 775 CPU Socket
P.8
DIMM1, DIMM2 DDR2 Module Socket 240-pin DDRII Module Socket P.18
PCI1~ PCI4 32-bit PCI Slots 32-bit PCI Local Bus Expansion slots P.20
PE1 PCI-Express x16 Slot PCI-E x 16 Expansion Slot
P.20
