USER MANUAL
485C COMPRESSOR KIT
Wiring Diagram:
(Fuse Not Included)
SINGLE “C” MODEL
COMPRESSOR WIRING DIAGRAM
15 Edelman
Irvine, CA 92618
949-585-0011
www.viaircorp.com
87
86
30
85
+
-
Battery
To Keyed
Power Source
40A Relay
Fuse
Pressure
Switch
Rev.1
LIMITED WARRANTY:
VIAIRCorporationwarrantsthisproduct,whenproperlyinstalledandundernormalconditionsofuse,tobefreefromdefectsin
workmanshipandmaterialsforaperiodofoneyearfromitsoriginaldateofpurchase.Toreceivewarrantyserviceorrepair,please
contactVIAIRCorporation.
Returnsshouldbemadewithinoneyearofthedateofpurchase,afteraReturnGoodsAuthorization(RGA)numberhasbeen
assignedbyVIAIRCorporation.ToobtainRGA,faxacopyofyourreceiptto(949)585-0188.Forcompletewarrantydetails,please
visit:www.viaircorp.com/warranty
PLEASE NOTE:
THISWARRANTYCOVERSPRODUCTDEFECTSONLY;ITDOESNOTCOVERINCIDENTALORCONSEQUENTIALDAMAGES
ASRESULTOFMISUSEORABUSE.
ThisManualisproprietarytoVIAIRCorporationandnoownershiprightsareherebytransferred.NopartoftheManualshallbe
used,reproduced,translated,converted,adapted,storedinaretrievalsystem,communicatedortransmittedbyanymeans,forany
commercialpurpose,includingwithoutlimitation,sale,resale,license,rentalorlease,withoutthepriorexpresswrittenconsentofVIAIR.
VIAIRdoesnotmakeanyrepresentations,warrantiesorguarantees,expressorimplied,astotheaccuracyorcompletenessofthe
Manual.UsersmustbeawarethatupdatesandamendmentswillbemadefromtimetotimetotheManual.Itistheuser’sresponsibility
todeterminewhethertherehavebeenanysuchupdatesoramendments.NeitherVIAIRnoranyofitsdirectors,ofcers,employees
oragentsshallbeliableincontract,tortorinanyothermannerwhatsoevertoanypersonforanyloss,damage,injury,liability,costor
expenseofanynature,includingwithoutlimitationincidental,special,directorconsequentialdamagesarisingoutoforinconnection
withtheuseoftheManual.
15EDELMAN•IRVINE,CA92618
TEL:(949)585-0011•FAX:(949)585-0188
www.viaircorp.com
AMERICAN WIRE GAUGE GUIDE 12-VOLT:
AmpDraw
Lengthofwirefrombatteryto
compressor(infeet)
5 10 15 20
5 16 16 16 14
10 16 14 12 10
15 16 12 10 10
20 14 10 10 8
25 14 10 8 6
30 12 10 8 6
40 12 8 6 6
50 10 6 6 4
60 10 6 4 4
