Page 8 of 12 August 2015
Vantage
Quick Start
Guide
Set up your Vicon Vantage system
Start the software
1 On your Windows desktop, double-click
the shortcut for the required Vicon
software.
2 If this is the first time you have used your
Vicon application software on this PC, a
dialog box may be displayed, enabling you
to specify the license server.
3 In the System Resources pane (in Blade,
the Selection editor), make sure all of the
cameras in your system are listed.
4 Ensure that at the top left of the screen
the system is shown as live and connected.
Position the cameras
1 In the System Resources pane (in Blade,
the Selection editor), select a camera.
2 Change the View pane to Camera view (or
in Blade, click the Camera Layout button
and ensure you are looking at a Capture
view).
3 Aim the camera so that it points where
required, usually the center of the capture
volume.
4 Repeat the process for each camera.
The diagram (right) shows typical camera
coverage of the capture volume.
