Viconics VT7200 Series User Manual

16 | PIR Ready VT7200 Series-Installation Guide
Occupied setpoints adjustments
Unoccupied and stand-by setpoints adjustments
Setting of the stand-by and unoccupied setpoints is done through the network or through
configuration setup only.
Mode button menu sequence
Modes presented to the user are dependent on the sequence of operation selected.
Default mode is shown in bold when sequence of operation parameter is changed.
System mode function
PLEASE NOTE THAT: Default system mode of operation is dependent on sequence of
operation selected
Default mode is in bold when sequence of operation parameter is changed
The available mode can only be changed through the network since there is no local
mode access
SEQUENCE SELECTED
MODE MENU
0 = Cooling Only
Off - Cool
1 = Heating Only
Off - Heat
2 = Cooling With Electric Reheat
Off – Auto – Heat – Cool
3 = Heating With Electric Reheat
Off - Heat
4 = Cooling and Heating ( 2 modulating outputs )
Off – Auto – Heat – Cool
5 = Cooling / Heating ( 2 modulating outputs) with
reheat
Off – Auto – Heat – Cool
INSTALLER CONFIGURATION PARAMETER MENU
Configuration can be done through the network or locally at the Terminal Equipment
Controller.
 To enter configuration, press and hold the middle button (°C/°F or Override) for
8 seconds.
 If a password lockout is active, “Password” is prompted. Enter password value
using the “up” and “down” arrows and press the middle button again to gain
COOLING
MODE
HEATING
MODE
OFF
MODE
AUTO MODE
 Setpoint presented to user is the setpoint from
the last action taken by the Terminal
Equipment Controller or the one currently in
use.
 Both heating and cooling setpoints are
changed simultaneously while respecting the
minimum configured deadband
Cool XX.X
°F or °C
Heat
XX.X
°F or °C
No access
to setpoint
Cool XX.X °F or °C and Heat XX.X °F or °C
Both heating & cooling setpoints change
simultaneously
