Viconics VT7200 Series User Manual

6 | PIR Ready VT7200 Series-Installation Guide
Network ready
 All Viconics VT7200 series Terminal Equipment Controllers are designed for
stand-alone (Network Ready) operation.
 They can be fully integrated into your choice of automation systems using the
available communication adapter options.
 If required, stand-alone (Network Ready) Terminal Equipment Controllers can be
field retrofitted with the following communication adapters:
o VCM7300V5000B, Terminal Equipment Controller BACnet™ MS-TP
communication adapter
o VCM7300V5000E, Terminal Equipment Controller Echelon™ Lontalk™
communication adapter
o VCM7000V5000W Terminal Equipment Controller wireless
communication adapter
TERMINAL, IDENTIFICATION AND FUNCTION
Viconics Part Numbers VT7200C5x00(x) Viconics number VT7200F5x00(x)
Description / Application 1 or 2 Floating outputs Description / application 1 or 2 Analog outputs
1 or 2 On/Off outputs
4- 24 V~ Hot 24 V~ Hot 4- 24 V~ Hot 24 V~ Hot
5- 0 V~ Com 24 V~ Com 5- 0 V~ Com 24 V~ Com
6- Aux BO 5 BO 5-Aux 6- Aux BO 5 BO 5-Aux
7- Aux BO 5 BO 5-Aux 7- Aux BO 5 BO 5-Aux
8- BO 3 Open Heat BO 3
9- BO 4 Close Heat BO 4 9- AO 2 Heat AO 2
10- BO 1 Open Cool BO 1 10- AO 1 Cool AO 1
11- BO 2 Close Cool BO 2 Not used Blank Blank
12- BI 1 BI 1 12- BI 1 BI 1
13- RS RS 13- RS RS
14- Scom Scom 14- Scom Scom
15- BI 2 BI 2 15- BI 2 BI 2
16- UI 3 COS / COC /SS UI 3 16- UI 3 COS / COC /SS UI 3
