Viconics VT7600 Series User Manual

10 | 028-0228-06 November 2015
Sequence of auto-scroll status display:
ROOM
TEMPERATURE
CLOCK
STATUS
SYSTEM
MODE
SCHEDULE
STATUS
OUTDOOR
TEMPERATURE
ALARMS
x.x °C
or °F
XX % RH
Monday
12:00
AM
Sys mode
auto
Occupied
Outdoor
x.x °C or°F
Service
Sys mode
off
Occupied
hold
Frost
ON
Sys mode
heat
Unoccup
SetClock
Sys mode
cool
Filter
Sys mode
emergency
Fan lock
Outdoor air temperature
 Outdoor air temperature display is only enabled when outdoor air temperature sensor is
connected.
 A maximum range status display of 50 °C ( 122 °F ) indicates a shorted sensor.
Associated functions, such as mode lockouts and economizer function are
automatically disabled.
 A minimum range status -40 °C ( -40 °F ) is not displayed and indicates a opened
sensor or a sensor not connected. Associated functions, such as mode lockouts and
economizer function are automatically disabled.
Alarms
 If alarms are detected, they will automatically be displayed at the end of the status
display scroll.
 During an alarm message display, the back lit screen will light up at the same time as
the message and shut off during the rest of the status display.
 Two alarms maximum can appear at any given time.
 The priority for the alarms is as follows:
