ASSEMBLYPROCEDURES
Text
7
Fitting the grasscatcher
• Stoptheengine.
•Raisetherearflapandhookthegrasscatcheronthebarattherearofthemoweras
shown in figures 1 and 2.
• Toremovethegrasscatcher,lifttherearflapandgraspthehandleonthegrasscatcher
and unhook from the rear bar.
Grasscatcher - 16in model
 Neverusethemowerunlessthegrasscatcherand/ortherear 
flaparecorrectlyassembledandfitted.
 STOPtheenginebeforefittingorremovingthegrasscatcher.
Fig. 1 Fig. 2
Rear flap
