4
Need Help? Watch the video at www.victortech.com/High-Rise
Step 2: Attach Tower to Steel Base
For safety, two people must perform the following steps.
1. Place the Tower in the upside down position on a flat sturdy table as shown below.
2. Position the Steel Base over the tower. Five holes on the steel base will match five
holes on the bottom of the tower. Make sure the felt pads are facing up.
3. Take the bolts and hand feed them through the Base into the Tower. Hand-tighten
the bolts until nearly tight. Keep bolts slightly loose until all are connected.
4. Use the small Hex Key to tighten the bolts more securely. Do not over tighten.
5. Invert the assembly to position the Steel Base on the table for the next step.
The Tower will be packaged in a compressed position. Do not loosen the knobs until the
Tower is attached to the Base. This will make assembly easier.
