Victory Dartboard Cabinet User Manual

PARTS IDENTIFIER
H5 (to scale) H6 (to scale) H7
H1 H2 (to scale) H3 (to scale) H4 (to scale)
Mounting Bracket
1 pc
3.5x10 mm
Phillips Head Screw
2 pcs
3 mm Nut
2 pcs
4 mm Flat Washer
2 pcs
5 x 20 mm
Phillips Head Screw
1 pc
1.5x18 mm
Phillips Head Screw
3 pcs
Bumper
3 pcs
H8 (to scale)
4x50 mm
Phillips Head Screw
4 pcs
H10 (to scale)
20 mm EVA Pad (Peel & Stick) - 4 pcs
(2 pcs customer installs & 2 pcs factory preinstalled)
H9 (to scale)
4.5 mm Flat Washer
4 pcs
H11
16” Template for
Mounting Dart Cabinet -1 pc
H12 H13 (to scale)
Door Hinge - 4 pcs
H14 (to scale)
3x12mm Flat
Head Screw
4 pcs
4x12mm Rounded
Head Screw
28 pcs
P1
Cabinet Body
1 pc
P2
Scoreboard
2 pcs
P3
Cabinet Door - Right
1 pc
P4
Cabinet Door - Left
1 pc
- 2 -
