Darting Game Rules
Various darting websites are available that explain darting rules and other specifics of the game.
- 8 -
Install Dartboard into Cabinet
Step.3
1. Install H5 Mounting Screw to the pilot hole which is marked with black marker on the back center of the dartboard and
leave approx. 1/8” of the screw head exposed from the backboard per shown on Figure 3.1. (This will allow you to
“Hang” the dartboard onto mounting bracket which was intalled in Step 1).
2. Install 3 pcs H7 Bumper to 3 pilot holes onto the back of the dartboard using 3 pcs H6 Bumper Screw and tighten, do
not strip out screws. Please see Figure 3.2.
H5
H6
H7
1/8"
Note: Leave 1/8” gap
Figure 3.1 Figure 3.2
3. Hang the dartboard onto the cabinet by hanging the dartboard center screw onto the H1 Mounting Bracket slot.
Note: While Figure 3.1 shows a 1/8” gap in order to hang the dartboard onto the hanger, a small amount of “adjusting”
may be required on the H5 center screw in order to achieve the best fit for the dartboard onto the cabinet.
4. Rotate and adjust Number “20” at the top.
Please see Figure 3.3.
Number “20” at the top
Figure 3.3
*NOTE: Cabinet doors not shown for clarity.
Bumper
Center
