1) LED INDICATOR
2) IR SENSOR
3) STAND BY
4) SOURCE (TV/AV)
5) MENU
6) CH-
7) CH+
8) VOL-
9) VOL+
10) AC POWER CORD
11) IF IN
12) RF IN
14) HDMI 1
13) VGA IN
A) Front Panel Control/Keys (Optional)
1 2
9
8
7
6
5
4
3
16) USB
17) SMART CARD SLOT
18) VGA AUDIO IN
19) AV OUT
20) YPbPr
21) AV 2 IN
22) AV 1 IN
8
15) HDMI 2
Note :
1) Point 10 is Optional.
VGA IN
IF IN
AV 1 IN
VGA
AUDIO IN
13
RF IN
YPbPr
AV 2 IN
20
21
USB
HDMI 2
HDMI 1
12
11
B) connecting your Unit:- (Optional)
2) Above sketch and connectivity are just for representation actual product may look
different as per model selection.
19
16
15
14
17
18
AV OUT
22
23
ETHERNET
23) ETHERNET
10
4.2 NAMES AND FUNCTION OF CONTROLS ON SET
