Rev AA Control Panel 3-3
Videojet 1710 Operator Manual
Arrow Keys
The arrow keys (item 2) allow the operator to navigate through the software
menus.
Keypad
The keypad (item 3) is 72 key, QWERTY, membrane type with tactile response
keys. The solvents that you use for printing and maintenance do not damage the
keypad.
Display
The Quarter Video Graphics Array (QVGA) Liquid Crystal Display (LCD) (item
5) has a resolution of 320
x 240 pixels. The LCD has an LED backlight to help
you see in low light conditions.
Contrast Keys
The contrast keys (item 6) help the operator to increase or decrease
the contrast of the LCD.
Function Keys
The following four function keys provide the basic printer controls (item 7):
Start or stop the ink jet
Select a message for printing
To enter the password
View and edit the messages
For more information on function keys, refer to “Soft Keys” on page 5-4.
