VIDEOJET 1710 - Page 37

Rev AA Ink Compartment 3-7
Videojet 1710 Operator Manual
Gutter Pump/Valve Module
The gutter pump/valve module (Figure 3-7) contains the fluid control valves,
gutter pump, pressure transducer and flush pump as a module arrangement for
ease of maintenance.
2
3
1
Figure 3-6: Ink Core Module
1. Manifold Mounted Pump
2. Dampener Cover
3. SPI Core Mixer Valve
Figure 3-7: Gutter Pump/Valve Module Assembly
