4-28 How to Print Messages Rev AA
Videojet 1710 Operator Manual
3 Press the Enter key to select the message for printing. The selected message
appears in the WYSIWYG of the display.
How to Start the Printing
The default sequence is Clean Start.
Note: You can select the option of Quick Start to activate the inkjet. The service
technicians use this feature. Refer to the service manual for more information.
1 Press the F1 key to start the jet start sequence.
During the sequence, the jet running icon flashes on the display. The
sequence takes approximately one minute. When the sequence is completed,
the icon is turned on continuously.
2 To start the printing process, the following operations are required:
• The print must be enabled (access Print > Print Enable. The Print Control
menu appears. Select Enable (Quick Key: ALT + F1).
• The product sensor must send a trigger signal.
• It may be necessary to adjust message parameters.
• The photocell level may need to be changed (access Configure > Photocell
Levels).
Note: When the print is enabled, the green LED on the keypad is turned on
continuously.
Monitor the Printing
When the printer is in the operation, use the following to monitor the status:
• The status icons on the display
• The LEDs on the keypad
•The stack light (optional)
How to Stop the Printing
Disable the print to stop the printing (access Print > Print Enable. The Print
Control menu appears. Select Disable (Quick Key: ALT + F1).
You can use the Clean Stop or Quick Stop sequences to stop the jet along with
stopping the printing. The default sequence is Clean Stop. The Quick Stop
sequence is used by service technicians. Refer to the service manual for more
information.
