5. Select and Configure the VCR Ports
• If you have a mixer or switcher, Edit Suite's VCRA port must match the
mixer's input A or input 1; VCRB must match the mixer's input B or input
2, and so on. VCRR is for the record VCR.
• If you are not using a mixer/switcher, configure VCRR for your record
VCR and any of the other ports for your source VCR(s).
To configure the ports—
A. Press
and
to move the cursor to the VCR port you want to
configure, then—
press
to display the first screen of Configuration Parameters for that
port.
VCRA VCRB VCRC VCRD
VCRR GPI-M GPI-T
PROTO=NONE
VCR=001 PREROLL=05
Configuration Menu Configuration Parameters
