B.Use the information below to determine and set the values for the PROTO,
VCR, TCSRC and TC parameters.
PROTO Type of control protocol. Your choice here should match
the type of cable you identified in Step 1. The choices are:
NONE Either this port is not used, or a noncontrollable source—
such as a live camera—is connected to the corresponding
port on your mixer/switcher. In either case, no cable is
attached to this Edit Suite control port and no other
parameters need to be specified for this port.
IR Infrared is used (record VCR only [VCRR]).
LANC Sony LANC (Control-L) protocol is used.
PANA Panasonic 5-pin (Control-M) protocol is used.
232 RS-232 protocol is used.
422 RS-422 protocol is used.
To select a protocol, with the cursor in the PROTO field
press
repeatedly to cycle through the list of choices. Stop when
the value you want is displayed.
If RS-232 protocol is selected, choices for baud rate and character
format display. Check the manuals for your VCR to
determine these values. To change values, press the
left/right arrow keys to move the cursor to the field, then
press [CHG] repeatedly until the correct choice is
displayed.
NOTE: If your record VCR uses IR, after configuring all of your play
VCRs, skip to Step 6.
