Viega Advantix - Media; Drainage Capacity

Technical information, see Ä Chapter 2.3.2 „Technical data“ on page 8.
The drain with a horizontal drain socket is suitable for both mounting in
a floor opening as well as for mounting on the floor.
The side inlet not serves as an odour trap.
The water seal level of 30 mm and the small drainage
capacity do not meet the specifications pursuant to the
standards and regulations. See Ä „Regulations from sec‐
tion: Fields of application“ on page 6.
Check if the drainage capacity is sufficient before mounting!
2.2.2 Media
The drain is intended for draining of household-type wastewater in con‐
stant operation, see Ä „Regulations from section: Media“ on page 6.
n The short-term temperature of the wastewater may reach up to
95° C. The temperature must be considerably lower in constant
operation.
n The pH value must be higher than 4 but lower than 10.
It is not permitted to introduce wastewater which would damage the
product material.
2.2.3
Drainage capacity
Drainage capacity at an accumulation height of 10 mm above the grate:
0.45 l/s
Drainage capacity at an accumulation height of 20 mm above the grate:
0.5 l/s
Drainage capacity through the lateral inlet: 1.2 l/s
The values are dependent on the total height of the drain unit.
10
20
Product information
Advantix bath drain 7 from 21
