6
Observe the information on electrical connections in
the installation and service instructions.
In the case of a power supply with power-OFF
facility, the power to the control circuit (heat pump
control unit) must be supplied without interruption by
the power supply utility.
Identification of electrical equipment (in accordance
with IEC 81346-2):
Example: /7.5
/ = cross-reference
7. = sheet number
5 = current path
Electrical equipment
B Pressure switch, temperature switch, thermal relay
E Instantaneous heating water heater
F Fuse, thermal relay
J Plug-in connector
K Contactors, relays
M Motor, circulation pump, motorised valve, compressor
N Controller
Q Mains isolator, power contactor, output relay
R Start-up resistor
S Control switch
X Terminals, plugs
Y 3-way diverter valve
Notes
Notes
6152053
