Connecting the Modbus cable between the indoor and outdoor unit
Outdoor unit with 1 fan
Types 101.B04 to B06
X18
CN12
Fig. 45
Type 101.B08
X18
CN12
Fig. 46
Installation sequence
Electrical connection (cont.)
6199585
Installation
