Viessmann VITOCAL 100-S - Wall Mounting

20
B
C
D
A
4x
2.
4x
1.
Fig. 14
A
Support for floorstanding installation (accessories)
B
Gravel bed as condensate soakaway
C
Concrete foundations: See Chapter "Foundations".
D
DN 125 KG conduit (only for line entry below
ground level)
Wall mounting
Installation should only be performed with the bracket
sets for wall mounting (accessories).
Separate installation instructions
Installation sequence
Installing the outdoor unit (cont.)
6199585
Installation
