70
Deactivating the service menu
The service menu remains active until it is disabled
with "Terminate service?", or if no key is pressed for
30 min.
Setting parameters using "System scheme 7000"
as an example
To set a parameter, first select the parameter group
and then the parameter.
Service menu:
1. Press and hold OK + å simultaneously for
approx. 4 s.
2. Select "Coding level 1".
3. Select parameter group: "System definition"
4. Select parameter: "System scheme 7000"
5. Set a system scheme: e.g. "6"
Alternatively, if the service menu was already active:
Extended menu:
1. å
2. "Service"
3. Select "Coding level 1".
4. Select parameter group: "System definition"
5. Select parameter: "System scheme 7000"
6. Set a system scheme: e.g. "6"
Required heat pump parameters
"Output compressor stage 5030"
During commissioning, the heating output of the heat
pump must be set subject to type.
Types 101.B04 101.B06 101.B08 101.A12 101.A14 101.A16
"Output compressor stage 5030" 4 kW 6 kW 8 kW 12 kW 14 kW 16 kW
Required parameters for components connected on site
Parameters may need to be set subject to the appli-
ance type, the selected system scheme and the acces-
sories used.
Overview of required parameters: See the following
chapter.
Detailed explanations of parameters
"Vitotronic 200" service instructions
System scheme
Overview of all available system schemes
Component System scheme
0 1 2 3 4 5 6 7 8 9 10 11
Heating circuit
A1/HC1 — X X — — X X — — X X —
M2/HC2 — — — X X X X X X X X —
M3/HC3 — — — — — — — X X X X —
DHW cylinder X — X — X — X — X — X —
Immersion heater 0 — 0 — 0 — 0 — 0 — 0 —
Heating water buffer cylinder — 0 0 X X X X X X X X —
Heating water/coolant buffer cylinder — 0 0 0 0 0 0 0 0 0 0 —
External heat generator 0
0
*1
0
*1
0 0 0 0 0 0 0 0 —
*1
Only in conjunction with a buffer cylinder
Commissioning, inspection, maintenance
Commissioning the system (cont.)
6199585
