Outdoor unit: Viessmann NTC 20 k
Ω
(no marking)
ϑ / °C R / kΩ ϑ / °C R / kΩ ϑ / °C R / kΩ ϑ / °C R / kΩ ϑ / °C R / kΩ ϑ / °C R / kΩ
–25 265.500 1 62.130 27 18.320 53 6.403 79 2.577 105 1.164
–24 249.900 2 59.080 28 17.550 54 6.167 80 2.495 106 1.131
–23 235.300 3 56.190 29 16.800 55 5.942 81 2.415 107 1.099
–22 221.600 4 53.460 30 16.100 56 5.726 82 2.339 108 1.069
–21 208.900 5 50.870 31 15.430 57 5.519 83 2.265 109 1.039
–20 196.900 6 48.420 32 14.790 58 5.320 84 2.194 110 1.010
–19 181.400 7 46.110 33 14.180 59 5.130 85 2.125 111 0.983
–18 171.400 8 43.920 34 13.590 60 4.948 86 2.059 112 0.956
–17 162.100 9 41.840 35 13.040 61 4.773 87 1.996 113 0.930
–16 153.300 10 39.870 36 12.510 62 4.605 88 1.934 114 0.904
–15 145.000 11 38.010 37 12.000 63 4.443 89 1.875 115 0.880
–14 137.200 12 36.240 38 11.520 64 4.289 90 1.818 116 0.856
–13 129.900 13 34.570 39 11.060 65 4.140 91 1.763 117 0.833
–12 123.000 14 32.980 40 10.620 66 3.998 92 1.710 118 0.811
–11 116.500 15 31.470 41 10.200 67 3.861 93 1.658 119 0.790
–10 110.300 16 30.040 42 9.803 68 3.729 94 1.609 120 0.769
–9 104.600 17 28.680 43 9.420 69 3.603 95 1.561 121 0.749
–8 99.130 18 27.390 44 9.054 70 3.481 96 1.515 122 0.729
–7 94.000 19 26.170 45 8.705 71 3.364 97 1.470 123 0.710
–6 89.170 20 25.010 46 8.370 72 3.252 98 1.427 124 0.692
–5 84.610 21 23.900 47 8.051 73 3.144 99 1.386 125 0.674
–4 80.310 22 22.850 48 7.745 74 3.040 100 1.346 126 0.656
–3 76.240 23 21.850 49 7.453 75 2.940 101 1.307 127 0.640
–2 72.410 24 20.900 50 7.173 76 2.844 102 1.269 128 0.623
–1 68.790 25 20.000 51 6.905 77 2.752 103 1.233 129 0.607
0 65.370 26 19.140 52 6.648 78 2.663 104 1.198 130 0.592
Maintenance
Checking the temperature sensors (cont.)
