Type AWOT-M-E/AWOT-M-E-AC 221.A04 221.A06 221.A08 221.A10 221.A13 221.A16
Air intake temperature
Cooling mode (type
AWOT-M-E-AC only)
■
Min. °C 10 10 10 10 10 10
■
Max. °C 45 45 45 45 45 45
Heating mode
■
Min. °C –20 –20 –20 –20 –20 –20
■
Max. °C 35 35 35 35 35 35
Heating water (secondary cir-
cuit)
Minimum flow rate l/h 700 700 700 1400 1400 1400
Minimum volume in the heating
system, cannot be fitted with
shut-off devices
l
50/40
*3
50/40
*3
50/40
*3
50/40
*3
50/40
*3
50/40
*3
Max. external pressure drop
(RFH) at minimum flow rate
mbar 705 705 705 500 500 500
kPa 70.5 70.5 70.5 50 50 50
Max. flow temperature °C 60 60 60 60 60 60
Outdoor unit electrical values
Rated voltage, compressor 1/N/PE 230 V/50 Hz
Max. operating current, com-
pressor
A 13.0 14.6 14.6 19.9 23.3 23.3
Cos ϕ 0.99 0.99 0.99 0.99 0.99 0.99
Starting current, compressor A 15 15 15 15 15 15
Fuse rating A 16 16 16 25 25 25
IP rating IPX4 IPX4 IPX4 IPX4 IPX4 IPX4
Indoor unit electrical values
Heat pump control unit/PCB
■
Rated voltage, control
unit/PCB
1/N/PE 230 V/50 Hz
■
Power supply fuse rating 1 x B16A
■
Internal fuse 6.3 A (slow)/250 V
Instantaneous heating water
heater
■
Rated voltage 1/N/PE 230 V/50 Hz
or
3/N/PE 400 V/50 Hz
■
Heating output kW 9
■
Power supply fuse rating 3 x B16A
Max. power consumption
Fan W 45 45 115 2 x 45 2 x 45 2 x 45
Outdoor unit kW 2.85 3.20 3.30 4.55 5.08 5.08
Secondary pump (PWM) W 60 60 60 60 60 60
■
Energy efficiency index EEI ≤ 0.2 ≤ 0.2 ≤ 0.2 ≤ 0.2 ≤ 0.2 ≤ 0.2
Control unit/PCB, outdoor unit W 15 15 15 15 15 15
Control unit/PCB, indoor unit W 10 10 10 10 10 10
Control unit/PCB power, indoor
unit
W 1000 1000 1000 1000 1000 1000
*3
When using the heating water buffer cylinder Vitocell 100-E, type SVPA, part no. ZK03801 in the secondary circuit return
