Type AWOT-M-E/AWOT-M-E-AC 221.A04 221.A06 221.A08 221.A10 221.A13 221.A16
Refrigerant circuit
Refrigerant R410A R410A R410A R410A R410A R410A
■
Refrigerant charge kg 1.40 1.40 1.40 2.40 2.40 2.40
■
Global warming potential
(GWP)
2088 2088 2088 2088 2088 2088
■
CO
2
equivalent t 2.9 2.9 2.9 5.0 5.0 5.0
Compressor (hermetically
sealed)
Type Scroll Scroll Scroll Scroll Scroll Scroll
■
Oil in compressor Type 3 MAF
POE
3 MAF
POE
3 MAF
POE
3 MAF
POE
3 MAF
POE
3 MAF
POE
■
Quantity of oil in compressor l 0.76 0.76 0.76 1.17 1.17 1.17
Permissible operating pressure
■
High pressure side bar 43 43 43 43 43 43
MPa 4.3 4.3 4.3 4.3 4.3 4.3
■
Low pressure side bar 28 28 28 28 28 28
MPa 2.8 2.8 2.8 2.8 2.8 2.8
Integral DHW cylinder
Capacity l 220 220 220 220 220 220
Max. draw-off volume at DHW
temperature 40 °C, storage
temperature 53 °C and draw-off
rate 10 l/min
l 290 290 290 290 290 290
Performance factor N
L
to
DIN 4708
1.6 1.6 1.6 1.6 1.6 1.6
Max. draw-off rate at the speci-
fied performance factor N
L
and
DHW heating from 10 to 45 °C
l/min 17.3 17.3 17.3 17.3 17.3 17.3
Max. permissible DHW temper-
ature
°C 70 70 70 70 70 70
Outdoor unit dimensions
Total length mm 546 546 546 546 546 546
Total width mm 1109 1109 1109 1109 1109 1109
Total height mm 753 753 753 1377 1377 1377
Indoor unit dimensions
Total length mm 681 681 681 681 681 681
Total width mm 600 600 600 600 600 600
Total height mm 1874 1874 1874 1874 1874 1874
Total weight
Outdoor unit kg 102 102 103 145 145 145
Indoor unit kg 164 164 164 164 164 164
Indoor unit with filled DHW cyl-
inder
kg 384 384 384 384 384 384
Permissible operating pres-
sure, secondary side
bar 3 3 3 3 3 3
MPa 0.3 0.3 0.3 0.3 0.3 0.3
