Viessmann Vitocell 100-L Service Instructions For Contractors

15
Vitocell 100-L
Type CVL CVLA CVLA
Cylinder capacity l 500 750 950
DIN registration no. Applied for
Standby heat loss q
ST
at 45 K temperature differ-
ential (actual values to EN 12897:2016)
kWh/
24 h
1.95 2.28 2.48
Dimensions
Length a (7) Excl. thermal insulation mm 650 790 790
Incl. thermal insulation mm 859 1062 1062
Width b Excl. thermal insulation mm 837 1005 1005
Incl. thermal insulation mm 923 1110 1110
Height c Excl. thermal insulation mm 1844 1817 2123
Incl. thermal insulation mm 1948 1897 2197
Height when tilted Excl. thermal insulation mm 1860 1980 2286
Weight
Cylinder Excl. thermal insulation kg 136 235 284
Incl. thermal insulation kg 156 260 314
Connections (male thread)
DHW inlet from heat exchanger R 2 2 2
Cold water, DHW R 2 2 2
DHW circulation, drain outlet R 1¼ 1¼ 1¼
Immersion heater for installation in the Vitocell with 500 l capacity
Rated output in standard mode/quick heat-up kW 2 4 6
Current type and rated voltage 3/N/PE 400 V/50 Hz
Rated current A 8.7
Heat-up time from 10 to 60 °C with a cylinder ca-
pacity of:
500 l h 12.6 6.3 4.2
Immersion heater, possibly in conjunction with heating lance, for installation in the Vitocell with 750 and
950 l capacity
Rated output in standard mode/during
quick heat-up
kW 2 4 6 4 8 12
Current type and rated voltage 1/N/PE 230 V 3/N/PE
380 V,
L
3/N/PE 380 V
Rated current A 8.7 17.4 8.7 10 20 17.3
Heat-up time from 10 to 60 °C with a cyl-
inder capacity of:
750 l h 16.30 8.15 5.43 8.15 4.07 2.72
950 l h 20.65 10.32 6.88 10.32 5.16 3.44
Specification
Specification
5677344
Appendix
