Vitotrans 353 (freshwater module)
Draw-off rate 25 l/min, 48 l/min, 68 l/min
Freshwater module for hygienic DHW heating in accordance with the
instantaneous water heater principle.
Available for wall mounting as types PBSA, PBMA and PBLA or as
types PZSA and PZMA for installation on the heating water buffer
cylinder Vitocell 100-E, Vitocell 120-E, Vitocell 140-E and
Vitocell 160-E.
Freshwater modules of the type for installation on the heating water
buffer cylinder include a DHW circulation pump and a diverter valve
for directed return stratification (also available for wall mounting as
an option).
All pumps are highly efficient.
With types PBMA (48 l/min) and PBLA (68 l/min), cascades with up
to 4 identical modules are possible.
2.2 Overview of product features
Cylinder Nominal ca-
pacity in l
Material Version Heat exchanger Colour
Type of to Stain-
less
steel
Enamel-
led
Steel
(buffer)
Horizon-
tal
Vertical Number Sep.
DHW
coil
Vitosilver White
Vitocell 100-H CHA 130 200 X X 1 X
Vitocell 300-H EHA 160 500 X X 1 X
Vitocell 100-V CVA
CVAA
CVAA-A
160 950 X X 1 X X
Vitocell 100-V CVWA 300 500 X X 1 X
Vitocell 300-V EVIA-A
EVIA-A+
160 500 X X 1 X X
Vitocell 100-W CUGA
CUGA-A
120 150 X X 1 X
Vitocell 100-L CVLA 500 950 X X X
Vitocell 100-B CVB
CVBB
300 950 X X 2 X X
Vitocell 100-U CVUB
CVUC-A
300 300 X X 2 X X
Vitocell 300-B EVBA-A 300 500 X X 2 X
Vitocell 340-M SVKA 400 400 X X X 1 X X
SVKC 750 950 X X X 1 X X
Vitocell 360-M SVSB 750 950 X X X 1 X X
All cylinders are supplied with thermal insulation. Cylinders with "-A"
(e.g. CUGA-A) or "-A+" (e.g. EVIA-A+) in their type designation are
additionally equipped with vacuum-insulated panels, enabling them
to achieve ErP energy efficiency class A or A+ respectively.
Vertical cylinders with a nominal capacity of ≤ 300 l are encased in
foam, as are horizontal cylinders. Vertical cylinders with a nominal
capacity of > 300 l are supplied with separate thermal insulation.
2.3 Intended use of Viessmann cylinders
The appliance is only intended to be installed and operated in sealed
unvented systems that comply with EN 12828 / DIN 1988, or solar
thermal systems that comply with EN 12977, with due attention paid
to the associated installation, service and operating instructions.
DHW cylinders are only designed to store and heat water of potable
water quality. Heating water buffer cylinders are only designed to
hold fill water of potable water quality. Only operate solar collectors
with the heat transfer medium approved by the manufacturer.
Intended use presupposes that a fixed installation in conjunction with
permissible, system-specific components has been carried out.
Commercial or industrial usage for a purpose other than heating the
building or DHW shall be deemed inappropriate.
Any usage beyond this must be approved by the manufacturer for
the individual case.
Incorrect usage or operation of the appliance (e.g. the appliance
being opened by the system user) is prohibited and results in an
exclusion of liability.
Incorrect usage also occurs if the components in the system are
modified from their intended use (e.g. through direct DHW heating in
the collector).
Adhere to statutory regulations, especially concerning the hygiene of
potable water.
Product information
(cont.)
DHW heating
VIESMANN
7
5414646
2
